UNV 300W AC Power Module

Specification How to buy PWR-300A-IN AC Input Voltage90264V AC Frequency4763Hz Power Factor≥0.95 Input Current≤4A@100VAC Input ProtectionInput undervoltage, Input overvoltage DC Output Voltage/Current+12VDC/25A, +12VStandby/0.7A Output Power312W Output Efficiency≥83%, 220V AC/25A Line Regulation±5% Load Regulation±3% Regulated Voltage Accuracy±5% Dynamic Response Overshoot±5% Current Sharing Rate±5% Output ProtectionShort Circuit Protection, Overload Protection, Overvoltage Protection, Hot Plug Protection, Over Temperature Protection Other Indicator lightNormal: green on, Abnormal: Yellow on Working Temperature0~55 Storage Temperature-40~70 Working Humidity10%~90% Heat dissipationVentilating fan design, heat emission at back Dimension (DHW)234.9mm40.13mm101.6mm Certification EMC standardsEN55022, EN55024 NEBS standardsGR-63-CORE ISSUE 2 Approved standardsCB, FCC, UL

AC Input Voltage 90264V AC Frequency 4763Hz Power Factor ≥0.95 Input Current ≤4A@100VAC Input Protection Input undervoltage, Input overvoltage DC Output Voltage/Current +12VDC/25A, +12VStandby/0.7A Output Power 312W Output Efficiency ≥83%, 220V AC/25A Line Regulation ±5% Load Regulation ±3% Regulated Voltage Accuracy ±5% Dynamic Response Overshoot ±5% Current Sharing Rate ±5% Output Protection Short Circuit Protection, Overload Protection, Overvoltage Protection, Hot Plug Protection, Over Temperature Protection Other Indicator light Normal: green on, Abnormal: Yellow on Working Temperature 0~55 Storage Temperature -40~70 Working Humidity 10%~90% Heat dissipation Ventilating fan design, heat emission at back Dimension (DHW) 234.9mm40.13mm101.6mm Certification EMC standards EN55022, EN55024 NEBS standards GR-63-CORE ISSUE 2 Approved standards CB, FCC, UL
