Mechanical
Dimensions Ø160 x 32.7 mm (Ø6.3 x 1.3")
Weight Without mount: 300 g (10.6 oz)
With mount: 315 g (11.1 oz)
Hardware
Networking interface (1) GbE RJ45 port
Power method PoE
Power supply UniFi PoE Switch
Max. power consumption 10.5W
Supported voltage range 44—57V DC
Max. TX power
2.4 GHz
5 GHz
23 dBm
26 dBm
MIMO <
2.4 GHz
5 GHz
2 x 2
4 x 4
Max. data rate
2.4 GHz
5 GHz
300 Mbps
1.7 Gbps
Antenna gain
2.4 GHz
5 GHz
2.8 dBi
3 dBi
Button (1) Factory reset
Mounting Wall/ceiling (Included)
Ambient operating temperature -10 to 70° C (14 to 158° F)
Ambient operating humidity 5 to 95% noncondensing
Certifications CE, FCC, IC, cULus
Software
WiFi standards 802.11 a/b/g/n/ac/ac-wave2
Wireless security WEP, WPA-PSK, WPA-Enterprise (WPA/WPA2, TKIP/AES)
BSSID Up to 8 per Radio
WMM Voice, video, best effort, and background
Concurrent clients 200+
Supported Data Rates (Mbps)
802.11a 6, 9, 12, 18, 24, 36, 48, 54 Mbps
802.11b 1, 2, 5.5, 11 Mbps
802.11g 6, 9, 12, 18, 24, 36, 48, 54 Mbps
802.11n 6.5 Mbps to 300 Mbps (MCS0 - MCS15, HT 20/40)
802.11ac 6.5 Mbps to 1.7 Gbps (MCS0 - MCS9 NSS1/2/3/4, VHT 20/40/80)
58 Mbps to 1.7 Gbps (MCS0 - MCS9 NSS1/2, VHT 160)
