The Klipsch Compact Performance Series CP-6 is a versatile speaker that brings powerful musical sound quality wherever you desire, indoors or out. Utilizing proprietary Tractrix® Horn technology for unmatched clarity and detail and a premium, long-throw woofer the sound is rich and dynamic well beyond its compact size.
FREQUENCY RESPONSE1 83Hz-22kHz +/- 3dB
POWER HANDLING2 75 w (300 peak) (8 ohm bypass)
MAX CONTINUOUS OUTPUT3
30 watt Tap
15 watt Tap
7v Tap
3.75 watt Tap
111 dB (8 ohm bypass)
105 dB 70 V/108 dB 100V
102 dB 70 V/105 dB 100V
99 dB 70 V/102 dB 100V
96 dB 70V/99 dB 100V
SENSITIVITY4 94 dB
NOMINAL IMPEDANCE 8 ohm (8 ohm bypass)
TWEETER .75" (1.9cm) aluminum dome tweeter
HIGH FREQUENCY HORN 90° x 90° Tractrix® Horn
WOOFER 5.25" (13.3cm) long-throw IMG woofer
CROSSOVER FREQUENCY 3kHz 12dB octave
ENCLOSURE TYPE Bass-reflex via dual front-firing ports
ENCLOSURE MATERIAL Anti-resonant, mineral-filled PPC;
paintable, weather resistant
GRILLE Powder-coated aluminum w/rotatable logo
TERMINALS Front baffle mounted accessed via rear pull-through
SPEAKER WEIGHT 6.85 lbs (3.1 kg)
SPEAKER DIMENSIONS 11.0"(27.9cm) H x 7.0"(17.8cm) W x 6.1"(15.5cm) D
SPEAKER DIMENSIONS W/ WALL MOUNT 11.0"(27.9cm) H x 7.0"(17.8cm) W x 6.9"(17.5cm) D
OTHER MOUNTING OPTIONS 1/4", 20-thread inserts on cabinet rear
FINISHES White/Black enclosure and grille
WIRE GAUGE ACCOMMODATED up to 16AWG
SOLD AS Speaker pairs
INCLUDED IN CARTON Speakers (x2), Grilles (x2), Brackets (x2), Manual,
Mounting Template, Bracket Retaining Screws (x4),
Safety Instructions, Grille Removal Tool
CARTON DIMENSIONS 15"(380mm) H x 19.5"(496mm) W x 10.6"(268mm) D
TOTAL CARTON WEIGHT 17.19 lbs.(7.8kg)
ITEM NUMBER 1060388 (white), 1016298 (black)
UPC 743878027044 (white), 743878025996 (black)
BUILT FROM 2014
Speaker Size:
6.5"
Style:
In-Ceiling
Integrated Backbox:
No
Speaker Type:
Standard
Application:
Residential
Brand:
TruAudio
.75” Aluminum tweeter mated to an exclusive 90° x 90° Tractrix horn
Highly-efficient, low-distortion, musical sound
Easy, front-access, one-screwdriver installation
Wall-mount with included bracket or place on table/shelf without
Also available as a 70/100 Volt speaker for commercial applications (CP-6T)
