SKU: SIM-S45-1150
MPN: S45-1150
UPC: 817777017762
Simply45 Shielded External Ground Standard WE/SS (8P8C) RJ45 Modular Plugs for (Cat6/6a STP), Solid 23AWG PE Insulated Wire Conductors 1.10-1.20mm/0.043"-0.047", Max Cable OD 8.0mm (0.315"); 2pc Plug with Bar45™ Load Bar, UL94 V0 Commercial Rated- 50pcs/Jar
Send to a friend!
Simply45® is the industry-leading brand for RJ45 modular plug innovation and performance solutions. Introducing the Simply45® S45-1150 Standard WE/SS (8P8C) Shielded with External Ground RJ45 Modular Plug for PE Insulated Wire Conductors such as found on Cat6 Shielded STP and Cat6a F/UTP LAN cables.
The Simply45® S45-1150 RJ45 shielded modular plug provides better signal isolation and terminated performance than other shielded RJ45 modular plugs for larger diameter Shielded LAN cables using PE (solid polyethylene) insulated wire conductors.
The S45-1150 incorporates the following features:
Two-Piece Plug. We tried all that we could to use a one-piece design, but it proved too difficult to work with during the testing trials. As such, we separated the metal shell shield from the RJ45 body. This allowed us to make additional modifications and the result is a dramatically improved termination process that is faster and easier to use. The metal shell quickly and easily snaps onto the plug body just prior to crimping. Separating the plug body from the metal shield allows the large-diameter shielded LAN cables to be inserted further into the plug. This is a significant advancement in RJ45 design because this feature improves NEXT performance by reducing the length of untwisted wires inside the plug. Please refer to our Technical Bulletin Its All About Those Twists for more information on how this feature raises RJ45 performance.
The S45-1150 supports performance standards: ANSI/TIA 568.2-D for Cat6a and Cat6; ISO/IEC 11801 Class Ea and E. Support 10GBaseT performance applications over PE insulated shielded twisted pair cables. For FPE-insulated shielded LAN cables typically found on 10G LAN cables, we recommend our S45-1155 Standard RJ45 solution or our ProSeries Shielded Pass-Through RJ45 modular plug S45-1755P.
Bar45® Load Bar. The exclusive Simply45® Bar45® are load bars designed to match specific Simply45® RJ45 modular plugs to improve termination performance and SIMPLIFY the termination process. The innovative S45-1150 Bar45® are designed specifically for our part S45-1150 and are the easiest-to-use load bars ever made for larger shielded LAN cables such as Cat6 STP and Cat6a F/UTP with PE insulated wires.
The S45-1150 Bar45® is designed specifically for our S45-1150 Standard Shielded with External Ground WE/SS (8P8C) RJ45 modular plug.
Simply45® is the industry-leading brand for RJ45 modular plug innovation and performance solutions. Introducing the Simply45® S45-1150 Standard WE/SS (8P8C) Shielded with External Ground RJ45 Modular Plug for PE Insulated Wire Conductors such as found on Cat6 Shielded STP and Cat6a F/UTP LAN cables.
The Simply45® S45-1150 RJ45 shielded modular plug provides better signal isolation and terminated performance than other shielded RJ45 modular plugs for larger diameter Shielded LAN cables using PE (solid polyethylene) insulated wire conductors.
The S45-1150 incorporates the following features:
Two-Piece Plug. We tried all that we could to use a one-piece design, but it proved too difficult to work with during the testing trials. As such, we separated the metal shell shield from the RJ45 body. This allowed us to make additional modifications and the result is a dramatically improved termination process that is faster and easier to use. The metal shell quickly and easily snaps onto the plug body just prior to crimping. Separating the plug body from the metal shield allows the large-diameter shielded LAN cables to be inserted further into the plug. This is a significant advancement in RJ45 design because this feature improves NEXT performance by reducing the length of untwisted wires inside the plug. Please refer to our Technical Bulletin Its All About Those Twists for more information on how this feature raises RJ45 performance.
The S45-1150 supports performance standards: ANSI/TIA 568.2-D for Cat6a and Cat6; ISO/IEC 11801 Class Ea and E. Support 10GBaseT performance applications over PE insulated shielded twisted pair cables. For FPE-insulated shielded LAN cables typically found on 10G LAN cables, we recommend our S45-1155 Standard RJ45 solution or our ProSeries Shielded Pass-Through RJ45 modular plug S45-1755P.
Bar45® Load Bar. The exclusive Simply45® Bar45® are load bars designed to match specific Simply45® RJ45 modular plugs to improve termination performance and SIMPLIFY the termination process. The innovative S45-1150 Bar45® are designed specifically for our part S45-1150 and are the easiest-to-use load bars ever made for larger shielded LAN cables such as Cat6 STP and Cat6a F/UTP with PE insulated wires.
The S45-1150 Bar45® is designed specifically for our S45-1150 Standard Shielded with External Ground WE/SS (8P8C) RJ45 modular plug.
| SKU | S45-1150 |
|---|---|
| Manufacturer | GoSimply Connect |
| Wire Type | 23 AWG, CAT6 |
| Connector Type | RJ-45 |
Cat6 Shielded
