Thermal Module
Image Sensor
Vanadium Oxide Uncooled Focal Plane Arrays
Resolution
640 × 512
Pixel Interval
17 μm
Response Waveband
8 μm to 14 μm
NETD
< 35 mk (25 °C, F# = 1.0)
Focal Length
75mm
IFOV
0.23 mrad
Field of View
8.3° × 6.6° (H × V)
Min. Focusing Distance
110 m
Aperture
F 1.0
Digital Zoom
×2, ×4, ×8
Image Effect
Target Coloration
Yes. Supported in white hot and black hot mode.
Smart Function
VCA
4 VCA rule types (line crossing, intrusion, region entrance, and region exiting), up to 8 VCA rules in total.
Temperature Measurement
3 temperature measurement rule types, 21 rules in total (10 points, 10 areas, and 1 line).
Temperature Range
-20 °C to 150 °C (-4 °F to 302 °F)
Temperature Accuracy
Max (±8 °C, ±8 %)
Fire Detection
Dynamic fire detection, up to 10 fire points detectable.
Video and Audio
Main Stream
50 Hz: 25 fps (1280 × 720, 704 × 576, 640 × 512,352 × 288)
Sub-stream
50 Hz: 25 fps (704 × 576, 640 × 512,352 × 288)
Third Stream
50 Hz: 25 fps (1280 × 720, 704 × 576, 640 × 512,352 × 288)
Video Compression
Main Stream: H.265/H.264
Sub-Stream: H.265/H.264/MJPEG
Third Stream: H.265/H.264/MJPEG
Audio Compression
G.722.1/G.711ulaw/G.711alaw/MP2L2/G.726/AAC/PCM
Network
Protocols
IPv4/IPv6, HTTP, HTTPS, 802.1x, Qos, FTP, SMTP, UPnP, SNMP, DNS, DDNS, NTP, RTSP, RTCP, RTP, TCP, UDP, IGMP, ICMP, DHCP, PPPoE
API
ISAPI, HIKVISION SDK, open network video interface
Security
User authentication (ID and PW), MAC address binding, HTTPS encryption, IEEE 802.1x (EAP-MD5, EAP-TLS), access control, IP address filtering
Simultaneous Live View
Up to 20 channels
Client
iVMS-4200, Hik-Connect
Web Browser
IE 11, Chrome 41-44, Firefox 30-51
Network Storage
MicroSD/SDHC/SDXC card (up to 256 G) local storage, and NAS (NFS, SMB/CIFS), auto network replenishment (ANR)
User/Host level
Up to 32 users, 3 levels: Administrator, Operator, User
Interface
Alarm Input
2, alarm input (0-5 VDC)
Alarm Output
2, alarm output
Alarm Action
SD recording/Relay output/Smart capture/FTP upload/Email linkage
Audio Input
1, 3.5 mm Mic in/Line in interface
Line input: 2 - 2.4 V [p-p], output impedance: 1 KΩ ± 10%
Audio Output
Linear level, impedance: 600 Ω
Communication Interface
1, RJ45 10 M/100 M self-adaptive Ethernet interface
1, RS-485 interface
1, Single Mode Fiber interface; TX: 1310 nm; RX 1550 nm; Transmission Distance: 20 km; Transmission Speed: 100 M;
General
Web Client Language
32 languages
English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Traditional Chinese, Thai, Vietnamese, Japanese, Latvian, Lithuanian, Portuguese (Brazil)
Power Supply
24 VAC ± 25%, two-core terminal block
PoE (802.3at, class 4)
Power Consumption
18 VAC to 30 VAC: 0.13 A to 0.22 A, max 5 W
9 VDC to 15 VDC: 0.37 A to 0.61 A, max 5 W
PoE (802.3at, class 4): 44 V to 57 V: 0.1 A to 0.13 A, max. 5.5 W
Working Temperature/Humidity
Temperature: - 40 °C to 65 °C (- 40 °F to 149 °F)
Humidity: 90% or less
Protection Level
IP67 Standard
TVS 6000V lightning protection, surge protection, voltage transient protection
Dimensions
535mm × 400mm × 171mm (21.06" × 15.75" × 6.73")
Weight
Approx. 6.40 kg (14.11 lb)
