Altronix NetWaySP4P2

4-Port Fiber Optic Transceiver

NetWaySP4P2

Altronix NetWaySP2PWP 3-Port PoE+ hardened switch with internal power converts a single Fiber (1000Base-X/SX/LX) into two (2) Ethernet ports (10/100/1000 Mbps) and provides PoE/PoE+ power to connected devices. Mounted in NEMA 4/4X, IP66-11 enclosure, it features auto detection and protection of legacy non-PoE cameras/devices.

Input

• 115VAC, 60Hz, 3.25A or 230VAC, 50/60Hz, 2A.

Power

• Four (4) 56VDC power-limited outputs up to 60W max. full power per port (240W total power).
• Short circuit protection.

Fiber Port

• Four (4) Gigabit SFP ports.
• Use with SFP module 1000Base-X (1Gb), compliant to Class 1 laser product (not included).

Ethernet

• Four (4) ports to switch.
• Wire type: 4-pair CAT5e and higher.
• Connectivity: RJ45, auto-crossover.
• Speed: Gigabit (1000Mbps).
• Distance: up to 100m.

Battery Charging

• Type: Sealed lead acid or gel type
• Failover: Upon AC loss, instantaneous
• (Batteries are sold separately).

Temperature

• Operating (120W): - 40° C to 50° C ( - 40° F to 122° F).
• Storage: - 40° C to 85° C ( - 40° F to 185° F).
• Relative Humidity: 85% +/- 5%.
• Operating Altitude: - 304.8 to 2,000m ( - 1,000 to 6,561.679 ft.).
• BTU/Hr. (approx.): 123 BTU/Hr.
