This reader handles all applicable ISO standards, are FIPS 201-1 compliant and reads 13.56 MHz contact-less smart cards. The reader interfaces with smart credentials and can read the card serial numbers of a variety of smart cards from other manufacturers, making your next upgrade in technology simple and seamless. Additionally, the reader is already NFC compatible and able to communicate with NFC-enabled phones whenever you’re ready to take that step.
Reader form factors are designed to fit a variety of placement needs, with an attractive modern design which will complement any facility’s architecture and décor. The reader is very easy to install with the quick-connect design and a standard wiring color scheme that most technicians are already accustomed to. But if you do have questions, you’ll never worry about lack of service or assistance. As always, our knowledgeable sales & support staff is ready to assist you with any design or technology questions you may have.
A proximity reader is part of an overall access control solution that would also include a door controller, door hardware and accessorie
Read Range
Up to 3.0"
Reader Type
mini-mullion
Card Compatibility
13.56 MHz
Physical Characteristics
Dimensions
4.26” H x 1.72” W x 0.81” D
Cable Distance
Wiegand Output: 500 ft. (152 m)
Certification
FCC , IC , UL 294 Listed, R&TTE Directive (15 EU Countries), CE Mark
Construction
PBT Polymer
Operating Temperature (F)
-40° ~ 158°
Product Color
Gray
Outdoor
Yes
Ingress Protection
IP65
Weight (oz)
4.0
Power Requirements
Amps DC (mA)
95 ~ 195
Volts DC
5 ~ 16
Other
Warranty
Limited Lifetime
Brand:
3x Logic
Accommodates interior, exterior, metal, and on-metal installation environments
Recognizes most smart credentials
NFC Compatible
FIPS 201-1 Compliant
Quick-connect design for easy installation
Simple wiring – color scheme is identical to most readers in the market
Easy-to-install mounting bracket
Tri-state LED (red, green, amber) visual indicator and audio feedback representing status and activity
information, easily discernible for the audibly or visually impaired
Wiegand output for simple interface with most access control panels
Multiple reader cover color options (black, brown and cream)
